Global design and BIM software provider Vectorworks has revealed several valuable updates to DIN SPEC, demonstrating industry-wide involvement, extensibility, and scalability
The GTDF format is the standard for describing the logical structure and controls of controllable devices in the lighting and entertainment industry.
The GDTF file format has continued to evolve with input and involvement from manufacturers across the globe and critical feedback from its many adopters, resulting in a newly published update to DIN SPEC 15800:2021.
‘A testament to the continued evolution and success of GDTF’
Vectorworks CEO, Dr Biplab Sarkar, said: “Receiving recognition in the form of a published update to DIN SPEC 15800:2021 is a testament to the continued evolution and success of GDTF.”
“The necessary work will continue to take place to ensure GDTF’s bright future so that its benefits can not only advance the work of the designers utilising it, but the entertainment industry as a whole.”
DIN, the German Institute for Standardisation, is the independent platform for standardisation in Germany and worldwide.
A DIN SPEC is a document that specifies requirements for products, services and processes, used as a strategic instrument to quickly and easily establish and disseminate innovative solutions that do not conflict with any existing standards or rules of procedure.
‘Serving the needs of the entertainment industry’
Michael Bahr, project manager at DIN, also commented: “The update to DIN SPEC 15800:2021 is a good example of how DIN SPECs can evolve and stay current with specifications that meet the needs of the market.
“GDTF and DIN SPEC 15800:2021 are clearly succeeding in serving the needs of the entertainment industry.”
“I’m happy that we could support this project and update this standard with the GDTF group. The updated DIN SPEC 15800:2021 will make the GDTF format easier to use and more scalable for the future. That’s what DIN SPEC is made for: ‘Today’s idea. Tomorrow’s standard’.”
DIN officially published GDTF as a publicly available specification for the entertainment industry worldwide in June 2020.
Since then, the original creators of the file format have been joined by manufacturers and users across the industry to ensure it remains the standard to truly benefit the end users.
Open communication, addressing feedback and continuous improvement efforts have led to the latest version of the file format, GDTF 1.2. GDTF 1.2 includes several major changes that address prior criticisms of the standard and key enhancements.
SVG and .gITF support
GDTF 1.2 includes SVG support for defining 2D representation and .gITF support for defining 3D representation, allowing for better graphical rendering for GDTF objects.
The additional support of these object types makes GDTF truly universal, not only targeting fixtures, but all kinds of objects that are used inside of an event.
Non-linear behaviour and SubPhysicalAttributes
The updated GDTF file format will provide support for non-linear behaviour of channel functions inside GDTF with DMX Profiles and better descriptions of the physical behaviour of channel functions with SubPhysicalAttributes.
The non-linear behaviour and SubPhysicalAttributes allow designers more precise rendering of F\fixture behaviours in rendering. In addition, channel functions that ramp, pulse or strobe can now be described more accurately.
Non-DMX Based Control Protocols
GDTF 1.2 delivers support for non-DMX based control protocols like OSC. This support for OSC demonstrates the file format’s ability to not only support DMX, but also other formats, providing design and production professionals with more flexibility and control.
GDTF 1.2 also provides support for more object types like trusses, lasers, hoists and power distributors with new geometry types.
Josef Valchar, CEO of Robe Lighting commented on this, stating: “A seemingly impossible task to allow standardised cross-manufacturer data exchange between devices in the lighting and entertainment industry has turned into a success story of industry-wide cooperation with the GDTF specification.”
“The continuous engagement of the GDTF group resulted in another GDTF update in the form of DIN SPEC 15800:2021, incorporating the feedback and work of many industry experts who contributed their expertise and time into a standard that allows their own products to utilise simpler yet more COMPREHENSIVE WORKFLOWS.”
‘Made by the industry for the industry’
“The GDTF group maintains a strong commitment to developing the format using open sources, while demonstrating responsiveness to critiques and requests to improve the formats,” said Gerhard Krude, managing director of MA Lighting Technology. “All in all, we emphasise that GDTF and MVR are made by the industry for the industry.”
To learn more about GDTF visit their website.
If you are at LDI2021, stop by to attend the free learning sessions on GDTF.
The updated DIN SPEC 15800:2021 will be published by Beuth Verlag sometime after LDI.
